HECATE ‘7 Carbon Fiber Frame – 7-Inch, 292mm Wheelbase, 4mm Arm Thickness for High-Speed FPV Racing

Description

Hecate’7 7 Inch 292mm Wheelbase 4mm Arm Thickness Carbon Fiber Frame Kit for RC Drone FPV Racing
Specification:
Model: Hecate’7
Item Name: 292mm Racing Frame Kit
Wheelbase: 292mm
Arm Plate Thickness: 4mm
Side Plate Thickness: 1.5mm
Other Plate Thickness: 2mm
Material: 3K Carbon Fiber
Weight: 132.6g approx.
Camera Mounting Width: 28mm
Recommend Parts:
Flight Controller: 30.5×30.5mm Flight Controller
Brushless ESC: 30.5×30.5mm 4 in1 ESC
Brushless Motor: 22XX Series Motor
Propeller: 7 Inch
Camera Mounting Width: 28mm
The following parts are suitable: ( Not Included)
Flight Controller: DYS F4 Pro V2  FC AIO OSD BEC & Current Sensor
Omnibus F4 FC AIO OSD BEC Current Sensor
Brushless ESC: DYS ARIA F45A Blheli_32 4 in 1 3-5S Dshot1200 ESC
Brushless Motor: Racerstar BR2207S 2200KV 2500KV 3-6S Brushless Motor
Propeller: Dalprop CYCLONE T7056C 7 Inch Crystal 3-blade Prop CW & CCW
Lipo Battery: 5S Lipo Battery   /   4S Lipo Battery
Pacakge Included:
1x Hecate’7 292mm Frame Kit
