ZTW Mantis Slim 15A SBEC Brushless ESC Speed Controller For RC Models
Mantis Slim is a high quality esc with complete product line, reliable performance. It contains 15A, 30A, 40A, 60A, 80A seven models from low to high voltage. Small and light, special for F3P and glider. The total 5 models esc were designed light, 6.8g only (without cable) for 15A. Light weight leave much adjust room to keep balance for frame. Mantis slim series ESC are special for F3P and glider.
Specification:
| Product Model | Mantis Slim 15A SBEC | |
| Model Number | 2015271 | |
| Type | brushed/brushless | brushless |
| High Voltage / Normal | Normal | |
| Specifications | Continuous Current | 15A |
| Burst Current | 25A | |
| Battery Cell | 5-12NC/2-4Lipo | |
| BEC output | 5V/2A | |
| Size | Width | 14mm |
| Length | 27mm | |
| Height | 5.5mm | |
| Weight | 6.8g | |
| Wires & Connectors | Power Wires | 20# AWG, 60mm-Red/60mm-Black |
| Motor Wires | 20# AWG, 60mm-Black | |
| Signal Wires | (Brownorange and red) 30C, 150mm a special JR male plug at one side | |
| Power plug | no | |
| ESC Programing via | Transmitter | yes |
| AIR Program Card | yes | |
| LED Program Card | ||
| LCD Program Card | ||
| WiFi Module | ||
| USB program connector | ||
| Firmware | Firmware Upgrade |
| Programmable Item/Tones | Option |
| Throttle Calibration | |
| (within the first 4 Sec )●● ●● ●● ●● | |
| 1 Brake | |
| _ * _ * _ * _ * | Brake On /Off |
| 2 Battery type | |
| ~ ~ ~ ~ | NiCad |
| ~ ~ ~ ~ ~ ~ ~ | LiPo |
| 3 Low Voltage Cutoff Threshold | |
| *_ _* *_ _* *_ _* *_ _* | Low2.8V/50% |
| *_ _ _* *_ _ _* *_ _ _* *_ _ _* | Medium3.0V/60% |
| *_ _ _ _* *_ _ _ _* *_ _ _ _* *_ _ _ _* | High3.2V/65% |
| 4 Restore Factory Setup Defaults | |
| — — — — | Restore |
| 5 Timing Setup | |
| – – – – | Automatic (7-30°) |
| – – – – – – – – | Low (7-22°) |
| – – – – – – – – – – – – | High (22-30°) |
| 6 Acceleration | |
| ∨∨ ∨∨ ∨∨ ∨∨ | Soft |
| ∨ ∨ ∨ ∨ | Normal |
| ∨∨∨ ∨∨∨ ∨∨∨ ∨∨∨ | Hard |
| 7 Heli Mode | |
| _*_ _*_ _*_ _*_ | Rpm off |
| _**_ _**_ _**_ _**_ | Heli Mode 1 |
| _***_ _***_ _***_ _***_ | Heli Mode2 |
| 8 Motor Rotation | |
| W W W W | Forward/ Reverse |
| 9 Switching Frequency | |
| // // // // | 8kHz |
| 16kHz | |
| 10 Low Voltage Cutoff Type | |
| – – – – | Reduce Power |
| – – – – | Hard Cut Off |
| Default | Brake: OFF Battery type Detect: LiPo with Automatic Cell Low voltage Cutoff threshold: Medium (3.0V/60%) Timing Setup: Automatic Acceleration: Soft Acceleration Heli Mode: RPM OFF Motor Rotation: Forward Frequency: 8kHz Low Voltage Cutoff Type: Reduce power |
Features:
* BEC built-in, easy to control.
* Great quality, reliable performance.
* Program card from Bea tles.
* Protect your beloved planes.
* Over temperature protection.
* Electrify safety.
Package Included:
1X ZTW Mantis Slim 15A SBEC
,
