ZOH-D KOPILOT Lite + VC400 FPV Autopilot Bundle – GPS Flight Controller with Piggyback OSD Camera & 5.8GHz 40CH VTX

Description

ZOHD Kopilot Lite And VC400 FPV Combo Autopilot System Flight Controller W/ GPS Module Plus VC400 PIGGYBACK AIO OSD Camera 5.8G 40CH VTX
Description:
Brand: ZOHD Item Name: Kopilot Lite And VC400 FPV Combo Quantity: 1set Package Size: 113*84*29mm Package Weight: 119g Usage: For FPV RC Airplanes Fixed Wing Model
Kopilot Lite Autopilot System Specification: Package Size: 113 X 84 X 29mm Package Weight: 83g Usage: For FPV RC Airplanes Fixed Wing Model
VC400 Specification:
Input voltage: 7-28V Frequency band: 5.8GHZ Video format: NTSC Camera resolution: 600TVL Antenna connector: Clover / Dipole  Field of View: 120 degrees Size: 24*15*10mm Weight: 8g Output power: 0.1mW / 25mW / 200mW / 400mW Operating current: 90mA (0.1mW) 150mA (25mW) 270mA (200mW) 360mA (400mW)   Kopilot Lite Autopilot System Highlights
* Easy Installation, minimal wiring. Super easy setup.
* Fast SAT lock.
* Return to Home (RTH) Fence (RAD) and Stabilization modes on a 3 position switch.
* Completely transparent. Switch it off and use it as a mixing board only.
* Supports T-Tail, V-tail and Flying Wing / Delta configurations.
* Launch assistant and motor blocking for no SAT fix.
* Adjustment board removable for a light-weight setup.
* Mini-size GPS unit for ultra-light setups.
* AIL, ELE, THR, RUD + AUX to control your servos. Landing gear and flaps go straight to RX.
* Computer-free programming.
* Easy to transfer between planes.
* Powerful stabilization and RTH algorithm.
VC400 Highlights * 3-in-1 AIO integrated design, with camera, VTx and antenna, ultra-light weight and small size, best solution for light-weight airplanes. * With OSD to show Power-on time and Input Voltage, so you can know how long you can keep flying. * Default JST plug and up to 25cm power cable, longer enough for most small size airplanes. * Up to 2.5km video transmission ra nge on 400mW. * Wide voltage input from 7-28V, safe for all kinds of battery or BEC input. * With customized ve1cro strap to hold the camera and EVA foam for anti-vibration. * Switchable between 0.1mW / 25mW / 200mW / 400mW. * Optional Clover / Dipole antenna for different airframes and flight mode (for straight line flights or flying around). * 5.8Ghz VTx with 40 racing channels. * Allows you to display customized Call Signs. * Power cable were soldering and fixed by silica glue, solid even in a crash.   Package Included: 1 X Kopilot Lite Set 1 X VC400 FPV Set
