WiFi-Enabled Mini T100 Metal RC Robot Tank Kit – High-Torque Chassis with ESPduino V1 Controller for Arduino Builders

Description

Chassis parameters:

• Name: Mini T100 Tracked Tank Chassis
• Material: Aluminum alloy
• Surface: sandblasted
• Colour: Black
• Track: Engineering Plastics
• Drive wheel: aluminum alloy
• Bearing wheel: aluminum alloy
• Size: about 185 * 200 * 60mm (length * width * height)
• Weight: 0.65kg
• Design load: 5KG

Motor parameters:

9V 150rpm motor: (with encoder)

12V 300rpm motor: (with encoder)

12V 330rpm motor: (without encoder)

33 motor: (without encoder)

ESPduino control kit:

• This kit consists of ESPDuino development board and 2-way motor board ＆ 16-way servo expansion board, which can be used to control tank/car chassis, robot arm, etc;
• ESPDuino is an Android UNO-compatible development board based on ESP826613, which supports WIFI;
• The 2-way motor board + 16-channel servo expansion board is a motor and servo drive module compatible with Android UNO and ESPDuino. The module adopts a stack-in circuit board design and can be directly connected to the Android UNO or ESPDuino circuit board.

Shipping list:

With 9V 150rpm/12V 300rpm/12V 330rpm/33 motor :

• 1 × mini T100 tank chassis
• 2 × DC motor
• 1 × ESPduino control kit
• Free:Acrylic panel, battery box, wrench, screw

ESPduino control kit:

• 1 × ESPduino development board
• 1 × Motor Driver board
• 1 × USB cable

Note:

• This product does not include a battery;
• In order to facilitate transportation, the product is not assembled.
• More documents can be downloaded at wiki.doit.am.
• If you need to install the manual, please leave your email after placing the order.
