URUAV Classics 240 FPV Drone Frame Kit – 240mm Wheelbase, 6mm Carbon Fiber Arms, 5-Inch Build

Description

URUAV Classics 240 240mm Wheelbase 6mm Arm Carbon Fiber 5 Inch Frame Kit for RC Drone FPV Racing
Specification:
Brand Name: URUAV
Model: Classics 240 Item name: 240mm 5 Inch Racing Frame Kit  Wheelbase: 240mm Material: Carbon Fiber Arm Thickness: 6mm Thickness of Top Plate: 2mm
Thickness of Bottom Plate: 2mm
Standoff Height: 30mm ( M3) Net weight: about 137g
Recommend Parts: Flight Controller: 20x20mm / 30.5×30.5mm F3 / F4 FC (Front Stack)
ESC: 20x20mm / 30.5×30.5mm 20A-30A 4in1 ESC (Front Stack)
FPV Transmitter: 20x20mm FPV Transmitter ( Back Stack ) Propeller: 5 Inch PropMotor: 2204 / 2205 / 2206 Motor (16×19)
Camera: Micro FPV Camera ( 19mm Width)
Lipo Battery: 4S 1500mAh Lipo Battery
The following parts are compatible: ( Not Included)
FC & ESC Flytower: 30.5×30.5mm DYS F4 Pro FC & F30A BL_S 4in1 ESC
20x20mm LDARC F4 OSD FC & 20A BL_S 4in1 ESC
FPV Transmitter:      20x20mm LDARC 5.8G 48CH 0/25/100/200mW VTX
Brushless Motor:     Racerstar SPROG X 2205 2300KV 3-4S Brushless Motor
DYS Samguk Series Wu 2206 2400/2700KV 3-4S Motor
Propeller:   2 Pairs Dalprop Cyclone T5046C 5046 5×4.6 3-Blade Propeller
10 Pairs Kingkong / LDARC 5040 5x4x3 3-Blade 5 Inch Propeller
FPV Camera:  RunCam Micro Swift 2 600TVL 1/3 OSD CCD FPV Camera
Lipo Battery: AHTECH Infinity 4S 14.8V 1500mAh 85C LiPo Battery XT
Package Included:
1x URUAVClassics 240 Frame Kit
