Description
Ultra Power UP300AC 300W LiIon/LiPo/LiFe/NiMH/NiCD Battery Touch Screen Charger Discharger
The UP300AC Touch Charger is a 300W, 20.0A AC/C Touch Screen charger, it can be used worldwide voltage 100-240V with its auto switching power supply, It can also be used as an independent power supply to power other devices, up to 300 Watts. It is capable of charging all types batteries, it include 3 sets fan cooling system and an internal sensor for controlling fan speed, internal cell balancers, touch screen display and important warning and safety function. Descrition: Brand: Ultra Power Item: UP300AC DUO Charger Input voltage: 100-240V(AC) 11.0-18.0V (AC) Charge Power: Max. 300W Discharge Power: Max.: 25W Charge current range: 0.1~20.0A Discharge current range: 0.1~5.0A LiIo/LiPo/LiFe/LiHv cell count: 1~6 series NiCd/NiMH battery cell count: 1 – 15cells Pb battery voltage: 2V~20V (1-10cells) Current drain for balancing LiPo: 500mA/cell Weight: 1.2KG Dimension: 180*139*60mm Usage: For LiIon/LiPo/LiFe/NiMH/NiCD Battery
| Battery Type | Number of Cells | Voltage Level | Max.Charge Voltage | Max.Fast Charge Rate | Min.Discharge Voltage |
| Nicd | 1-15 | 1.2V/Cell | 1.5V/Cell | 1-2C* | 0.85V/Cell |
| Nimh | 1-15 | 1.2V/Cell | 1.5V/Cell | 1-2C* | 1.0V/Cell |
| Li-Ion | 1-6 | 3.6/Cell | 4.1V/Cell | 1C | 2.5V/Cell |
| Lipo | 1-6 | 3.7V/Cell | 4.2V/Cell | 1C | 3.0V/Cell |
| Life | 1-6 | 3.3V/Cell | 3.6V/Cell | 4C | 2.0V/Cell |
| Pb(Lead Acid) | 1-10 | 2.0V/Cell | 2.46V/Cell | 0.4C | 1.75V/Cell |
Features: Charges 1-6 cell LiPo, LiFe and Li-ION, 1-15 cell NiCd and NiMH and 2-20V lead acid batteries Fast Charge, Balance Charge and Storage Charge modes for lithium batteries Automatically controls current rate during charging and discharging process Five user customizable pre-set per output Three fan cooling system with internal sensor for controlling fan speed Batteries can be set to automatically Charge/Discharge or Discharge/Charge up to a maximum of 10 cycles Automatic charge termination if battery temperature gets too high Temperature probe is required and must be purchased separately PC-based program can analyze the characteristics of each battery via a USB port, graph of voltage, current and capacity curves with individual voltage of each cell in a lithium pack can be displayed on a PC- *PC-LINK USB adaptor is required and must be purchased separately. Tow USB ports, 5 volts, 2100mA total for iPad, mobile phone, digital cameras, etc.
English Manual, Click Here Package Included: 1 x Ultra Power UP300AC 300W Touch Screen Charger
,
,
,
,
