SMA-KWE to RP-SMA Female RF Adapter – Low-Loss Connector for FPV Drone Antenna Systems

Description

Specification: Item name: RF Connector Adapter Connector: SMA-KWE to RP-SMA Female  Temperature range: -65 to +165 °C (PE Cable -40 to +85 °C) Vibration: MIL-STD-202, Method 213 Characteristic impedance: 50Ω Frequency range: DC ~ 12.4GHz (semi-rigid cable 0 ~ 18GHz) Operating voltage: 335V max (effective value) Withstand voltage: 1000V rms (minimum sea level) Contact resistance:  ≤ 3 mΩ between inner conductors ≤ 2 mΩ between outer conductors Insulation resistance ≥ 5000 MΩ Insertion loss ≤0.15 dB/6GHz Voltage standing wave ratio Straight flexible cable ≤1.10+0.002f Semi-rigid cable ≤1.05+0.001f Curved flexible cable ≤1.20+0.003f Semi-rigid cable ≤1.10+0.001f Durability ≥500 cycles
Package included: 1 x SMA-KWE to RP-SMA Female RF Connector Adapter for RC Drone
