Description:
Item Name: RC832HD FPV Receiver
Sensitivity: ≤-93dBm Working Frequency: ISM 5.8GHz Available Channel: 48CH Power Supply: DC 6-24V Consumption Current: 200mA, Max. Antenna Input Impedance: 50ohm Typ. Antenna Connector: SMA Antenna Gain: 2dBi Video Output Level: 1.0Vp-p Typ, 75Ω Audio Output Level: 1.0Vp-p Typ, 10KΩ Audio Carrier: 6.5MHz Type Standard: NTSC/PAL Dimension: 80x65x15mm Weight: 120g
Features:
– 48 channels: Cover A,B,E,F,Rbands and L band (Airwave band), 6bands and all frequencies compactable.
– Twoswitchingbuttons: CH button forfrequencies channels switching,FR button forfrequencies bands switching.
– Two digits display: one for CH and the other for FR, real-time positioningwhichfrequency band and which channel received.
– Power off memory: Re-play the very lastfrequency band and channel.
– Independent video and audio signal outputs.
Channel and Digital Tube Display:
Power on, press the “CH” button to change channel, “CH” digit display will change synchronously, “CH” digit display changes cyclically from 1 to 8.
Frequentand Digital Tube Display:
Power on, press the “FR” button to change frequency band, “FR” digit display will change synchronously, “FR” digit display changes cyclically from 1 to 6.
FR1 for A band, FR2 for B band, FR3 for E band, FR4 for F, FR3 for R band, FR3 for L band band(Airwave band).
Frequency and Channel Frequency Table:
|
CH FR |
CH (MHz) |
||||||||
|
CH1 |
CH2 |
CH3 |
CH4 |
CH5 |
CH6 |
CH7 |
CH8 |
||
|
FR |
FR1(A) |
5865M |
5845M |
5825M |
5805M |
5785M |
5765M |
5745M |
5725M |
|
FR2(B) |
5733M |
5752M |
5771M |
5790M |
5809M |
5828M |
5847M |
5866M |
|
|
FR3(E) |
5705M |
5685M |
5665M |
5645M |
5885M |
5905M |
5925M |
5945M |
|
|
FR4(F) |
5740M |
5760M |
5780M |
5800M |
5820M |
5840M |
5860M |
5880M |
|
|
FR5(R) |
5658M |
5695M |
5732M |
5769M |
5806M |
5843M |
5880M |
5917M |
|
|
FR6(L) |
5362M |
5399M |
5436M |
5473M |
5510M |
5547M |
5584M |
5621M |
|
Package Included:
1x RC832HD FPV Receiver
1x SMA Standard Type Dipole Antenna 1x Stereo Jack to RCA AV Output Cable 1x Power cable
