Radiolink Mini PIX F4 Flight Controller MPU6500 With TS100 M8N GPS UBX-M8030 for RC Drone FPV Racing
Description: 1. PIX F4 Flight Controller: Processor: STM32F405VGT6 Gyro: MPU6500 Barometer: LPS22HB Compass: QMC5883L Connector: JST GH connector Mavlink UART: 2(with CTSRTS) Size: 39*39*12mm Weight: 12g (without wires) Better altitude hold Same functions as PIXHAWK Same size as F4 Cost-effective DIY solution Top configuration Vibration damping by software Easy to control Comprehensive technical support 2. TS100 Mini M8N GPS Module: Size: 32*30*12mm Weight: 20g Positional accuracy: 50 centimeter precision when working with concurrent GNSS Velocity precision: 0.1m/s Max height: 50000m Max speed: 515m/s Max acceleration: 4G Max update rate: up to 10Hz Sensitivity: Tracking & Nav.: -167dBm, Reacquisition: -163dBm Cold start: -151dBm, Hot start: -159dBm Time to first fix: Cold start: 26s, Hot start: 1s Connect ports: Power supply: voltage 5VDC+-5%, current 50~55mA Ports: A. GPS UART interface baud rate: 1.2K/4.8K/9.6K/19.2K/38.4K/57.6K/112.5K B. Geomagnetic I2C interface Top configuration: GPS decoder chip: Radiolink M8N GPS, with u-blox UBX-M8030(M8), 72-channel, is much better than single GNSS 7N. Geomagnetic: QMC5883L which with same technology as HMC5983 form Honeywell Antenna: 2.5dbI high gain and selectivity ceramic antenna Double filter: SAWF(Surface acoustic wave filter) form Murata
Radiolink mini pix user manual
Package included: 1 x Mini PIX F4 flight controller 1 x TS100 Mini M8N GPS 1 x power module 1 x buzzer 1 x power module connect cable 1 x buzzer connect cable 1 x receiver & RSSI connect cable 1 x safety switch button
,
,
,
,
,
,
,
,
,
,
,
