Radiolink Mini GPS Module M8N (SE100): UBX-M8030 Chipset, Pixhawk-Compatible – Precision Navigation for Racing Drones & Quadcopters

Description

Radiolink Mini GPS System Module M8N SE100 for Pixhawk Flight Controller UBX-M8030 M8 Chip For RC Racing Drones and Quadcopter Specification:Brand name: RadiolinkItem name: M8N GPS ModulePositional Accuracy: 1m precision when working with concurrent GNSS, 2.5m precision when working with single GNSS.Velocity precision: 0.1m/sMax height: 50000mMax speed: 515m/sMax acceleration: 4GMax update rate: up to 18HzSensitivityTracking & Nav.: -167dBm; Reacquisition:-163dBm; Cold start:-151dBm; Hot start:-159dBmTime to first fix: Cold start: 26s, Hot start:1s.Power supply: voltage 3.3VDC+-5%, current 50~55mAPorts:A. GPS UART interface, baud rate: 1.2K/4.8K/9.6K/19.2K/38.4K/57.6K/112.5KB.Geomagnetic I2C interface   Feature: Top Configuration-GPS decoder chip: Radiolink M8N GPS, with u-blox UBX-M8030(M8), 72-channel, MMIC BGA715L7 from Infineon and 13 years of RF experiences, is much better than single GNSS 7N.   A.Concurrent reception of GPS/QZSS L1 C/A,GLONASS L10F, BeiDou B1   B.SBASL1 C/A:WAAS, EGNOS, MSAS- Antenna : 2.5dbI high gain and selectivity ceramic antenna- Power amplify IC: MMIC BGA715L7 from Infineon- Filter: SAWF(Surface acoustic wave filter) form Murata- Geomagnetic: HMC5983 Professional Design Radiolink M8N GPS, benefits from professional wireless experiences of Radiolink engineers, exceed the limitation of IC sensitivity index from circuit schematic design to PCB placement.1 meter position accuracy, positioning in 23 seconds and valley stationkeeping ability make Radiolink GPS much better than the similar products. High Performance Cost RatioReasonable price with better hardware, software configuration and brand new exterior designs.  Package Included:1 X  M8N GPS Module 1 X  Stent1 X  6pin to 5pin line
