PandaRC PM2207 Brushless Motor – 2207 Size, 2450KV/2750KV, 3–6S Compatible for FPV Drones

Description

PandaRC PM2207 2207 2450KV 2750KV 3-6S Brushless Motor for RC Drone FPV Racing
Specification:
Brand Name: PandaRC
Model: PM2207
Item Name: 2207 2450KV 2750KV 3-5S Motor
KV Version: 2450KV / 2750KV ( Optional)
Thread Version: CW Screws Thread
Lipo Cells:  3-6S Lipo (2450KV) ;
3-4S Lipo (2750KV)
Configuration: 12N14P
Stator Diameter: 23mm
Stator Length: 7mm
Shaft Diameter: 4mm
Motor Dimension: 27.5 x 19.5mm
Quantity: One PC
Weigt: 36g
Idle current (10)@10V(A): <2.0@2450KV ; <2.4@2750KV
Max. Continuous Power(W)180S: 1101@2450KV; 853.9@2750KV
Internal Resistance: 50.5mΩ@2450KV; 37.5mΩ@2750KV
Max Current(180S): 52.43A@2450KV ; 50.83A@2750KV
Max. Efficiency Current: (7.87-21.42A)>81%
Package Included:
1x PM2207 2450KV Motor
1x Motor Nut
1x bag of Screws
OR
1x PM2207 2750KV Motor
1x Motor Nut
1x bag of Screws
