Description
Features & Specifications Receiving frequency: 9CH (1080MHz to 1360MHz) RX Sensitivity: -95dBm Band-pass filter 950MHz~1450MHz Dual input options: 4~5V via pins or 6-30V via pads Button control and LED indicators On board regulator output: 5V 2A @ input voltage 6~30V Current Consumption: 0.3A @5V Video format: NTSC or PAL Video Output impedance: 75Ω, Typ. Audio Subcarrier Frequency: 6.5 MHz & 6.0MHz ANT. input impedance: 50Ω, Typ. RF Connector: SMA Weight: 14g ( w/o antanna) Size: board 43*27mm 2.54mm pins and PCB size are compatible with FS module Settings Press and hold the button 2 seconds to enter the frequency setting. Frequency LED blinks Press the button to select the frequency When the LED blinks at new frequency, RF input is enabled on this frequency. New frequency will be saved if no button action within 3 seconds Package Included 1 x 1.2/1.3G Video receiver VRX-1G3 1 x Dipole antenna_SMA, center freq 1240MHz
