Description
HGLRC Parrot120 Pro 120mm F4 Toothpick FPV Racing Drone PNP BNF w/ 1106 Motor Caddx.us Turbo Eos2
Specification:
Brand Name: HGLRC
Model: Parrot120 Pro
Item Name: 120mm F4 2.5 Inch Toothpick FPV Racing Drone
Version: PNP ( Without Receiver); With Frsky XM+ Receiver; With Flysky A8S V2 Receiver
Drone Wheelbase: 120mm
Material: Carbon Fiber
Arm Thickness: 2.0mm Standoff Height: 23mm Flight control installation holes: 16*16mm Support camera: 14X14mm Empty Frame Weight: 15g
Net Weight of Drone: 57.6g
| HGLRC FD411 Flight Controller | Item Name: FD411 Flight Controller MPU: MPU6000-SPI CPU: STM32F411CEU6 Black Box: NO Input Voltage: 2-4S Lipo Built-in Betaflight OSD to adjust PID BEC Output: 5V 2A Size: 21x21mm Installing Hole: 16x16mm, M2 Support SBUS/PPM/DSMX/iBUS receiver Weight: 2.7g |
| HGLRC FD13A BL_S 2-4S 4in1 ESC | Item Name: FD13A 4in1 2-4S ESC Input Voltage: 2-4S Lipo Constant Current: 13A Burst Current: 15A (5S) BEC Ouput: NO Size:23x24mm Installing Hole: 16x16mm, M2 Weight: 3.2g CPU: SILABS EFM8BB2 48MHZ MOS Tube: TOP QUALITY MOSFET Support Damped Mode: DSHOT600/300/150/Oneshot125/42, MultiShot, PWM |
| HGLRC FD 400mW VTX | Item Name: FD VTX Input Voltage: DC 5V Output Power: PIT/25mW/100mW/200mW/400mW Switchable PIT———0dBm——70mA 25mW—–14dBm—–150mA 100mW—-20dBm—–210mA 200mW—-23dBm—–280mA 400mW—-26dBm—–360mA Installing Hole: 16x16mm, M2 Size: 20x20mm Antenna: IPEX Weight: 1.5g |
| HGLRC HF1106 6000KV Brushless Motor | Item Name: HF1106 6000KV Brushless Motor Motor KV: 6000KV Stator Diameter: 11mm Stator Thickness: 6mm No. of Stator Arms: 9S No. of Rotor poles: 12P Motor Resistance: 120mΩ Max Continuous Current: 15.27A No. of Cells: 2-3S Lipo Recommended Propeller: 2.5 Inch Wire Type: 28AWG , 80mm Weight: 6g |
| Gemfan 2540 2.5Inch 3-Blade Propeller | Brand Name: Gemfan Item Name: 2540 2.5Inch 3-Blade Propeller Quantity: 3 CW & 3 CCW |
| Caddx.us Turbo Eos2 FPV Camera | Item Name: Turbo EOS2 Image Sensor: 1/3″ CMOS Horizontal Resolution: 1200 TVL TV System: NTSC / PAL (optional) IMAGE: 16:9 Synchronization: Internal Electronic Shutter: PAL: 1/50-100,000 NTSC: 1/60-100,000 S/N Ratio: more than 52dB (AGC OFF) Video Output: CVBS Lens: 2.1mm Auto Gain Control: YES BLC: YES WDR: Global WDR DNR: 2 DNR Dimension: 14x14x16mm Input Voltage: DC 3.3-6V Working Temperatur: -20℃ – +60℃ Work Humidity: 20%~80% Net weight: 3.5g |
| Optional Receiver Version | PNP ( Without Receiver); With Frsky XM+ Receiver; With Flysky A8S V2 Receiver |
| Lipo Battery ( NOT Included) | Recommend 2-3S Lipo |
Package Included:
1x Parrot120 Frame Kit
1x FD411 Flight Controller 1x FD13A 4in1 BLS ESC 1x FD VTX 4x HF1106 6000KV Brushless Motor 1x Caddx.us Turbo Eos2 FPV Camera 6x Gemfan 2540 2.5Inch 3-Blade Propeller 1x IPEX Antenna 1x Receiver ( Optional)
