Sale!

Hglrc Forward Fd2207 1775Kv 5-6S Brushless Motor For Rc Fpv Racing Drone 1

Hglrc Forward Fd2207 1775Kv 5-6S Brushless Motor For Rc Fpv Racing Drone 2

HGLRC Forward FD2207 1775KV Brushless Motor – High-Torque 5–6S Powerplant for FPV Racing Drones

Name: HGLRC Forward FD2207 1775KV Brushless Motor – High-Torque 5–6S Powerplant for FPV Racing Drones
Brand: DroneSpark
SKU: 1338863
Availability: InStock

Original price was: $33.99.Current price is: $22.66.

In stock

SKU: 1338863 Category: Motor Vehicle Electronics Brand: DroneSpark

Description
Reviews (0)

Description

HGLRC Forward FD2207 1775KV 5-6S Brushless Motor for RC FPV Racing Drone
Specification:
Brand name: HGLRC
Item name: Forward FD2207 1775KV Brushless Motor
Motor KV: 1775KV
Stator Diameter: 22mm
Stator Thickness: 7mm
No.of Stator Arms: 12S
No.of Rotor poles: 14P
No-load Current(A/10V): 1.3A
Motor Resistance: 65mΩ
Max Continuous Current(30s) : 16.3A
Max Continuous Power: 391W
Weight(Excluding Cable): 32g
Rotor Diameter: 27.5mm
Shaft Diameter: 5mm
Body Length: 17.3mm
Overall shaft Length: 30.7mm
No.of Cells(Lipo): 5~6S
ESC: 40~50A
Recommended Prop(inch): 5Inch
Wire Szie: 20AWG 150mm
Package Included:
1 X FD2207 1775KV Brushless Motor
