Description
Description:
FSESC6.6 with firmware VESC_default_no_hw_limits version, compatible with Benjamin VESC TOOL, can be used for models, multi-axis aircraft, electric vehicles, electric skateboards, golf carts, smart cars, robots, and simple industrial position control.
Item Brand:HGLRC-FLIPSKY Item name: FSESC6.6 60A ESC
With aluminum box packaging: Net weight: 380g Gross weight:550g,with the aluminium case; Aluminum box size:100mm*92mm*22.5mm Packaging size:200mm*140mm*40mm
For more information,you can click here
If you want the FSESC6.6+Aluminum Case+Button,go to here
With Heat sink packaging:
Net weight:125g
Packaging weight:300g
Packaging size:200mm*140mm*40mm
Spec
– Hardware: V 6.6 – Firmware: VESC_default_no_hw_limits – Voltage: 8V – 60V (Safe for 3S to 12S LiPo) – Voltage spikes may not exceed 60V – Current: Continuous 60A, Burst 150A. Values depend on the temperature and air circulation around the device – 5V 1.5A output for external electronics – 3.3V 1A output for external electronics – Modes: DC, BLDC, FOC (sinusoidal) – Supported sensors: ABI, HALL, AS5047 – include Anti-spark switch – include Waterproof aluminum case
Features – Measure current and voltage of all phases – Regenerative braking – Traction control (single and double settings) – Sensor or sensorless operation + hybrid mode – Configurable RPM, Current, Voltage and Power Limits – Input source: PPM, simulation, NRF Nyko Kama Nunchuck – Communication ports: USB, CAN, UART, NRF, bluetooth – Throttle curves and ramps for all input sources – Separate acceleration and brake throttle curves – Seamless four-quadrant operation – Motor speed, ampere hours, watt hour count – Instant data analysis and reading via communication port – Adjustable different protections: – Low input voltage – High input voltage – High motor current – High input current – High regenerative braking current (separate limit of motor and inpu
– High speed (separate limit in each direction).
– Over temperature (MOSFET and motor)
Package included:
1X HGLRC-Flipsky Rc Car Parts
1X USB micro Flash Charge VOCC Cable
1X Mini Micro JST 2.0 PH 3-Pin Connector plug with Wires Cables
1X Manual
