Description
Description:
Spec:
·Item brand:Flipsky
·Item name:Antispark Switch Smart 280A
·Size:49.5mm*33.5mm*12.7mm(Include Heatsink)
·Packaging size:200mm*140mm*40mm ·V2.1 ·PCB thickness: 6 layers*3oz copper=18oz copper ·Max continuous 280A, burst current 800A ·Max voltage: 13S (60V) ·Mosfets: NVMFS5C628NL ·PCBA Dimensions(with heatsink and heat shrink): 49.5*33.5*12.7mm ·LED Button cable length: 270mm ·LED button diameter:16mm
Function: Smart: skate your board to power on , Stay still for 3 minutes automatically power off LED button: press 1second to power on, press 2seconds to power off Reminder: Do not peel off the heat shrink in your application.There’s no screw to lock the heatsink and PCBA. Only the heat-transfer silicon pad is naturally sticky to heatsink and PCBA.
Recommedation:
The esc shown in the picture is not included;if you want to buy the esc,please click here
Package included:
1X Antispark Switch Smart 280A
