Everwing TH2306 2300KV Brushless Motor – Compatible with GT215, X220, and 250-Class FPV Drones

Description

Everwing TH2306 2306 2300KV 3-5S Brushless Motor for GT215 X220 250 RC Drone FPV Racing
36% Off Coupon: TH2306
Specification:
Brand Name: Everwing
Model: TH2306
Item Name: 2306 2300KV 3-5S Brshless Motor
Version: CW Screw Thread / CCW Screw Thread
KV: 2300KV
Configu Ration: 12N14P
Stator Diameter: 23mm
Stator Length: 6mm
Shaft Diameter: M5
Dimension: 32.6*28.5mm ( Dia. * Len)
Weight: 33g
Idle Current: 1.5A @ 10V
NO. of Cells Lipo: 3-5S
Max. Con. Current: 45.2A @180S Max.
Con. Power: 949.2W @ 180S
Max. Efficiency Current: 13-20A
Inrenal Resistance: 37.5mΩ
Package Included:
1x TH2306 Motor CW Or CCW
,,
