Dumborc 10A Dual-Direction Brushed ESC – Speed Controller with Brake Function for RC Cars, Boats & Airplanes

Description

Description:
Item Brand:DumboRC
Item Name:10A brushed esc
Material:Plastic and metal components
Color:As  the picture shown
Product Size:165*18*8.5mm
Product Weight:About 10g
Fit For:RC Vehicle Models Car Boat Tank Airplane,for 130/180 motor,1/24,1/28 car
Connection
CH2: electrically modulated signal line (6V output, supports high voltage) CH3: enable / disable control signal LED: connected to headlights (5V output) M1: Coupling motor BUZ: beep (low voltage signal) Power: Connect the battery
Features:
Lipo:2-3s UBEC:6V
Two way control(forward,reverse)
LED Lamp control
Low voltage alarm
Brake turn on/off
Two types of connection: Car controller: CH2: 2 channels CH3: 3 channels LED: Headlights M1: engine Buz: Low Voltage Alarm   Aircraft control panel CH2: 3 channels CH3: Connecting a two-stage switch LED: light lamp M1: engine Buz: Low Voltage Alarm   Lamp control: The output voltage of the channel connected to the LED is 5 V, which can be used as a high-level drive relay of the module. Can be connected to LED light, can also be used as an external switch with a high degree of reproduction.   Low voltage signal: Automatic identification battery 2 S / 3 S, the default alarm voltage of 2 S batteries is 7.2 v, and the default alarm voltage of 3 S batteries is 10.7 v
Package included:
1X 10A ESC
