BS-Series Brushless ESC for RC Airplanes and Boats – Hobby-Grade Programming Card Included

Description

Description:
Brand Name: Surpass Hobby
Item Name: Program card
Material: Metal and plastic
Main Color: Red
Product Size: 55*42.5*3.5mm(L*W*H)
Product Weight: 6.5g
Packaging Size: 90*60*10mm
Packaging Weight: Approx.12g
Application: RC Airplane/Boat BS Series Brushless ESC
How to Use: 1. Connect the ESC to the motor. 2. Set the blue jumpers on the programming card for the settings you want (see ESC instrustions for details on individual options). 3. Connect the Signal wire to the programming card connector marked “- + P”. 4. Connect the ESC to the battery pack. For the ESC without a built-in BEC (OPTO), you need to connect the extra power (4.8-6.0V) or UBEC to the connector marked “- +”. 5. You should hear one short beep to confirm that your settings are valid and have been stored. If you hear a long beep (about 10 seconds), the settings are invalid and have not been stored. Check your settings and start over. 6. Disconnect your battery pack and the programming card. 7. Your ESC is now programmed and ready to run.  Package included:
1X Program Card
