5.8GHz 14dBi Directional Patch Antenna – RP-SMA/SMA Fixed-Mount Panel Antenna for Long-Range FPV Racing & Fixed-Wing Drones

Description

5.8G 14dBi High Gain Panel Antenna for Fixed-wing/Multicopter

Description:

Specially designed for RC FPV, mini size, high gain, low SWR and high self recovery function at any angle.

Transmitting distance: 15km with 5.8G 1200mw VTX/RX.

5km with 5.8G 600mw VTX/RX.

Frequency: 5600-5950MHz

Gain-dBi: 14dBi

3db vertical beamwidth: 40 degree

3db horizontal beamwidth: 35 degree

Impedance: 50ohm

Polarization: Vertical

Sidelobe suppression>=13DB

VSWR: <=1.5

Front-to-back ratio: >=25DB

Maximum power: 50W

Connector: rp-SMA / SMA for choice

DC grounded.

High self recovery function.

Package Including:

1pcs* 14dBi High Gain Panel Antenna (as your choice)
