2 PCS 3Bhobby 3B-R 0804 Brushless Motor 7100KV 11900KV 2S/1S For RC Drone FPV Racing Multi Rotor
Description: Brand name: 3BHOBBY KV: 7100KV/119000KV No.of cells(Lipo): 2S/1S Stator diameter: 8mm Stator length: 4mm Shaft diameter: 1.5mm Motor dimension (Dia.*Len): Φ11.6×14.5mm Weight: 3.4g (excluding cable) Wire szie: 28AWG 80mm Recommend propeller: Gemfan 1.9″-2.5″ Recommend ESC: 6-12A Suit for: 60-90 frame
| Specifications | DATA | |
| Motor KV | 7100KV | 11900KV |
| Stator Diameter | 8mm | 8mm |
| Stator Thickness | 4mm | 4mm |
| No.of Stator Arms | 9S | 9S |
| No.of Rotor poles | 10P | 10P |
| No-load Current(A/4V) | 0.5A | 0.6A |
| Motor Resistance | 296mΩ | 157mΩ |
| Max Continuous Current | 4A | 6.3A |
| Max Continuous Power | 32W | 25.6W |
| Weight | 3.9g | 3.9g |
| Rotor Diameter | 11.6mm | 11.6mm |
| Shaft Diameter | 1.5mm | 1.5mm |
| Body Length | 11.5mm | 11.5mm |
| Overall shaft Length | 14.5mm | 14.5mm |
| No.of Cells(Lipo) | 2S | 1S |
| ESC | 6-12A | 6-12A |
| Recommended Prop(inch) | 1.9~2.5Inch | 2Inch |
| Wire Szie | 28AWG 80mm | 28AWG 80mm |
Package included: 2 x 0804 motor 12 x round head hex socket screws M2*4
